TBOX-PLUS (i3) (2T15)

The TBOX-PLUS is a rugged, compact fanless Box PC powered by 11th Gen Intel Core Tiger Lake processors. Designed for reliable operation in industrial environments, it offers flexible storage, improved, rich I/O connectivity, and wide-range power input support, making it ideal for automation, edge computing, and control applications.

Categories: Industrial, Industrial PC, Industrial PCs

Quick Spec

Processor	Intel Core i3-1115G4 processor
RAM	Up to 32Gb
SSD	Up to 512Gb M.2 2280
I/O Ports	USB 3.0 x 6, HDMI x 2, Audio
OS Support	Win10, Win11, Linux
Mounting Type	Desktop, wall mount

Datasheet

TBOX-PLUS (i3) (2T15)-Datasheet

Request a Quote Back to Product

Need Help? Contact Us

01462 374102
[email protected]

Rugged & compact, fanless designed box structure
Powerful Intel Tiger Lake UP3 11th Gen. Core i3-1115G4 processor
Single DDR4 memory, up to 32GB, 1x M.2 2280 storage slot
DC terminal 12V input, optional wide DC 9~36V power input
2x M.2 expansion slots
Industrial operating -20 ~ +70℃ temp. range

FULL SPECIFICATIONS

System

CPU	Intel 11th Gen. Core i3-1115G4 processor
Memory	Up to 32GB SO-DIMM, DDR4-2666/2933/3200 Mhz
TPM	Intel PTT TPM 2.0

I/O Port

USB	6x USB 3.0, 2x USB 2.0
Serial/Parallel	COM1/2/3/4/5: RS232, COM6: RS485 (optional RS232)
Audio	Mic-in/Line-out (2 in 1, 3.5mm Jack)
LAN	2x RJ45, 10/100/1000 Mbps
Power Connector	2 pin, phenix terminal
Option	3G/4G/5G/Wi-Fi/BT wireless
Display Ports	2* HDMI (Max. support 4096 *2160 @30Hz)

Storage

HDD	1x M.2 2280 M-Key slot (PCIe x4 Gen IV, NVMe) SSD
Option	1x 2.5” SATA III SSD

Expansion

Onboard Expansion bus

N/A

Display

Display Type	N/A
Max. Resolution	N/A

Touch Screen

Type	N/A
Light Transmission (%)	N/A

Power

Power Input

DC 12V (Optional wide DC 9~36V)

Mechanical

Construction	Aluminum alloy, anodizing and anti-scratch treatment
Mounting	Desktop, wall mount
IP Rating	N/A
Net Weight	1.6kg

Environmental

Operating Temperature	-20 ~ + 70 (℃)
Certificate	CE/FCC/ROHS
Operating System Support	Win10, Win11, Linux

TBOX-PLUS (i3) (2T15)-Datasheet
