AHM-6156P

Archive product – see alternative product
ARCHMI Panel PC

> 5 year warranty as standard on all products

Quick Spec

Display Size	15''
CPU Performance	Intel Atom/Celeron Dual Core
Mounting Type	Panel, VESA
IP Rating	Front IP65
Ambient Temperature	-10°c/50°c
Touchscreen	Projected Capacitive

Datasheet

AHM-6156P_ds.pdf

Request a Quote

Discontinued

Need Help? Contact Us

01462 374102
sales@dsl-industrialcomputing.co.uk

The AHM-6156P is a 15″ industrial Panel PC featuring an Intel Atom/Celeron Dual Core processor, designed for reliable operation in industrial environments where front IP65 protection and compact installation are required. The projected capacitive touchscreen provides responsive, precise input, and the unit supports both panel and VESA mounting for flexible integration into operator stations and control installations.

With an operating range of -10°C to +50°C and a fanless design, the AHM-6156P delivers dependable low-maintenance performance across a variety of light to medium industrial applications. Note: this is an archive product – please see current ARCHMI Panel PC alternatives for updated specifications and support.

0/5 (0 Reviews)

Intel Atom D525 processor, fan less design
IP65 Flat Panel Design with projected capacitive touch
Aluminum front bezel
Accessible 2.5″ SATA HDD space
11~32V DC Wide Range DC Power Input

System

CPU	Intel Atom D525 1.8 GHz DMI processor
Memory	1 x DDR3 SO-DIMM Slot, default 2GB
System Chipset	Intel ICH8M
External I/O Port	4 x USB 2.0 ports 2 x RJ-45 ports (GbE) 1 x DB-15 VGA 2 x DB-9 RS-232 COM1 and COM2 1 x DB-9 RS-422/485 COM3 default RS-485 1 x 3 pins terminal block DC power input 1 x 8 pins terminal block 2in/2out GPIO, power switch ±, VCC and ground 1 x Audio Line-out 3.5mm jack
Storage	1 x Accessible 2.5″” SATA HDD 1 x External CF Slot
Expansion Slots	None
Power Input	DC 11~32V
Touch Screen	Projected Capacitive Touch
Light Transmission	90%
OS Support	Windows CE 6.0, XP Pro, XP Embedded, Windows embedded standard 7

LCD

Display Type	15” TFT-LCD
Max. Resolution	1024×768
Max. Color	262K
Luminance (cd/m2)	400
View Angle	H: 160/V: 145
Backlight Lifetime	50,000 hrs

Mechanical

Construction	Aluminum front bezel and steel chassis
Mounting	Panel/VESA 75×75 Mount
IP Rating	NEMA 4/ IP 65 compliant front panel
Net Weight	6.3kgs
Dimension	410(W)x310(H)x73.5(D) mm
