FABS-918A/P

These 18.5″ lightweight stainless-steel, front IP66/IP69K panel PCs employ the Intel Core i5 6300U CPU, and can be panel or VESA mounted for a sleek built-in feel. Perfect for the food and beverage industry.

Category: Panel PCs

Quick Spec

Display Size	18.5''
Processor	Intel Core i5 6300U
RAM	4GB – 32GB
IP Rating	Front IP66/IP69K
Touchscreen	Projected Capacitive
OS Support	Windows 10 Pro/IoT, Linux, Ubuntu
Mounting Type	Panel/VESA

Request a Quote Back to Product

Need Help? Contact Us

01462 374102
[email protected]

18.5” Industrial Compact Size Panel PC
Stainless-Steel Bezel
Flat Front Panel Touch Screen and Fanless Design
DC 9~36V Wide-Ranging Power Input
Intel Core i5 6300U CPU built-in
Up to 32GB RAM
IP66/IP69K Compliant Front Panel

System

CPU	Onboard Intel Core i5 6300U Processor
Memory	Onboard 4GB DDR4

I/O Port

USB	2 x USB 3.0 type A
Serial/Parallel	1 x DB-9 RS-232/422/485, COM1 (default RS-232) 1 x RS-232 DB-9, COM2
Audio	1 x Audio Line Out
LAN	2 x GbE LAN RJ-45
Power Connector	1 x 3-pin for DC power input terminal 1 x 2-pin connector for power on/off button
Option	4G LTE/WiFi/BT 4 x USB 2.0 type A (TB-528U4) 4 x USB 2.0 type A + 1 x Mini-PCIe + 1 x SIM slot (TB-528U4ME1) 2 x COM (RS-232) (TB-528C2) 1 x COM (RS-232) + 2 x USB 2.0 (TB-528C1U2) 1 x COM (RS-232) + 2 x USB 2.0 + 1 x Power Button (TB-528C1U2P1) 2 x COM (RS-232) + 1 x Mini-PCIe slot + 1 x SIM slot (TB-528C2ME1) 2 x COM (RS-422/485, isolated) (TB-528C2I) 2 x CAN (TB-528CAN2) 1 x LAN + 2 x USB 2.0 type A (TB-528E1U2) 1 x LAN(45W isolated PoE PD) + 2 x USB 2.0 type A (TB528E1U2UPOE) Backup Battery 21W/10.8V/1.95Ah(3S1P) System is only allowed to build in either TB-528 PoE series or backup battery

Storage

HDD	1 x 2.5″ SATA3 HDD bay for SATA HDD (Easy Accessible)

Expansion

Expansion slot

1 x Internal Mini-PCIe slot full size

Display – based on standard display, high brightness option see datasheet

Display Type	18.5″ TFT-LCD
Max. Resolution	1366 x 768 (1920 x 1080 option)

Touch Screen

Type	Projected Capacitive / Resistive / Glass
Light Transmission (%)	over 90%

Power

Power Input

DC 9~36V

Mechanical

Construction	304 Stainless steel front bezel (316 option) Aluminium die-cast chassis
Mounting	Panel Mount, VESA Mount 100 x 100
IP Rating	Front Panel IP66/IP69K
Net Weight	6.9kg

Environmental

Operating Temperature	0~50°C/-20~60°C (option)
Certificate	CE/FCC Class A
Operating System Support	Windows 10 Pro/IoT, Linux, Ubuntu
