FABS-118P

These 18.5″ lightweight stainless-steel, front IP66/IP69K industrial displays can be panel or VESA mounted for a sleek built-in feel. Perfect for the food and beverage industry.

Quick Spec

Display Size	18.5''
IP Rating	Front IP66/IP69K
Touchscreen	Projected Capacitive, Resistive, No Touch Hardened Glass
Mounting Type	Panel/VESA

18.5” Industrial Compact Size Industrial Display
Stainless-Steel Bezel
Flat Front Panel Touch Screen and Fanless Design
DC 9~36V Wide-Ranging Power Input
IP66/IP69K Compliant Front Panel

I/O Port

VGA	1 x VGA
DVI	1 x DVI-D (share with HDMI)
DP	1 x DP
HDMI	1 x HDMI (share with DVI-D)
Audio	1 x Audio line-in phone jack
Power Connector	1 x 3-pin terminal block for DC 9~36V power input
Others	1 x USB type B for touch control Optional I/O: 1 x Speaker
Display	based on standard display, high brightness option see datasheet
Display Type	18.5″” TFT-LCD
Max. Resolution	1366 x 768 (1920 x 1080 option)

Touch Screen

Type	Projected Capacitive/Resistive/Glass
Interface	USB interface
Light Transmission (%)	over 90%

Power

Power Input

DC 9~36V

Mechanical

Construction	304 Stainless steel front bezel (316 option) Aluminium die-cast chassis
Mounting	Panel Mount, VESA Mount 100 x 100
IP Rating	Front Panel IP66/IP69K
Net Weight	6.58kg
